Temperature control on Masterbuilt smoker.

  • Some of the links on this forum allow SMF, at no cost to you, to earn a small commission when you click through and make a purchase. Let me know if you have any questions about this.
SMF is reader-supported. When you buy through links on our site, we may earn an affiliate commission.

Icefever

Newbie
Original poster
Jul 1, 2018
14
5
Warwick UK
Hi guys..

I bought an MBS about 6 months back used it a few times, to do ribs & tri-tip....not too sure if I'm running correctly??.the temp control is all over the place.

I've been making bacon for a couple of years now...(dry cure)...this morning I had 3 slabs of cured bacon and we decided to smoke 2 of them. Now, normally I cold smoke using a maze, and keep the temp under 20c....then cool, slice, vac-pack, & freeze.

I'd been reading & watched TulsaJeff's video on smoking bacon, so this morning I set up the smoker at 180°F (82°C) , popped in the bacon with temp probes in both and one for an internal temp of the smoker....I've never done this method were you smoke up to where it reaches 145°F (63°C).

Now, this is where it went pear-shaped, the temp inside the smoker shot up to 92c...I use an Inkbird 4 probe one for when I'm using the BBQ.

I tried the air vent in a number of slots, wide-open down to almost closed. After trying for maybe an hour without success, I resorted to opening the door an inch and used gaffer tape to hold at this. this seemed to help, but it's not what you want when your smoking, now I'm thinking about what was going on??.any advice or tips.

Is it because the bacon was dry-cured instead of wet?? I can't see that making any difference at all???

Did it go to 92°C and stay there, or was that the high end of a Temp Swing?
+/-10°C (20°F) Swings are normal for the MES smokers with that older style controller. It is also not unusual for a separate Thermometer to read a 10°+ difference in temp at the meat grate compared to what the MES display says.
MES owners set the Smoker Temp by what the temp at meat level is and ignore what the Smoker Controller says the temp is...JJ

Many thanks guys....

Did it go to 92°C and stay there, or was that the high end of a Temp Swing?
+/-10°C (20°F) Swings are normal for the MES smokers with that older style controller. It is also not unusual for a separate Thermometer to read a 10°+ difference in temp at the meat grate compared to what the MES display says.
MES owners set the Smoker Temp by what the temp at meat level is and ignore what the Smoker Controller says the temp is...JJ
Yes JJ...at the start, then through most of the day it was swinging 80c/92c, at one point where I didn't want the bacon to cook anymore, that was when I opened the door so that the temp would drop quickly, which it did down to around 70c.
It's a shock to learn that there is such a large difference in temp swing :emoji_astonished: I didn't expect that from a manufacturer like MB,

@ Brokenhandle.
@ Ringer.
chopsaw chopsaw .

I came to the same conclusion yesterday about using a PID. I built one many years back for brewing beer, I use an inkbird one on a fridge at the moment as a fermentation chamber.

I've now ordered one from Amazon with a thermocouple, I have an SSR in the garage so I'll knock up a box this week, do you guys pass the thermo through the top air vent??? I don't want to drill the cabinet just yet.


Cheers Ice.

  • Like
Reactions: chef jimmyj
Many thanks guys....


Yes JJ...at the start, then through most of the day it was swinging 80c/92c, at one point where I didn't want the bacon to cook anymore, that was when I opened the door so that the temp would drop quickly, which it did down to around 70c.
It's a shock to learn that there is such a large difference in temp swing :emoji_astonished: I didn't expect that from a manufacturer like MB,

@ Brokenhandle.
@ Ringer.
chopsaw chopsaw .

I came to the same conclusion yesterday about using a PID. I built one many years back for brewing beer, I use an inkbird one on a fridge at the moment as a fermentation chamber.

I've now ordered one from Amazon with a thermocouple, I have an SSR in the garage so I'll knock up a box this week, do you guys pass the thermo through the top air vent??? I don't want to drill the cabinet just yet.


Cheers Ice.
I drilled a small hole on the side of mine... mine wasn't long enough to go through top. I didn't want my auber sitting on top of my mes as it's not insulated and top gets warm.

Ryan

  • Like
Reactions: Icefever
do you guys pass the thermo through the top air vent??? I don't want to drill the cabinet just yet.
I did mine through the back . Look through this thread . Shows how I did it if you're interested .

  • Like
Reactions: Icefever
Thanks, guys you've put my mind to rest, the smoker is not a complete waste of time, :emoji_wink:.
Waiting now on Amazon bringing the PID, may find some time tomorrow to start the DIY `bit.

Ice.

I drop my PID probes through the vent but I made sure I got 6ft+ length probes.

It sounds like you have a good handle on what you are doing if you've built a PID controller before.

The MES you have is physically built very well, that's its strength.
I think Masterbuilt intentionally has the temp swings to ensure wood chips will continue to burn by having longer "on" cycle temp ramp up.

Once you change to a PID you will likely need to also use an A-Maze-N Pellet Smoker (AMNPS) tray or tube with pellets to generate smoke. This is not an issue as almost all of us use the AMNPS no matter what. Can't beat it!

I recently built a MyPin PID controller for my brother's smoker. The project box/enclosure is the worst part by far. Be sure you get one that is large enough. I don't think you can go too large but damn it's hard to find a decent box haha. Best of luck!

It sounds like you have a good handle on what you are doing if you've built a PID controller before.
I'm not too bad I can follow a wiring dia....or think it through what should it do and what does it do :emoji_laughing:...
Why do you still use a maze, why not feed via the cabinet tube??

I've got my thinking head-on at the moment, I would like to be able to use the pid controller on my beer mash/boiler.
I have a Klarstein boiler that has two elements a 1.5Kw & a 3Kw....I'm now thinking about being able when I want to use it with either the smoker or boiler??

Ice.

Last edited:
They are so cheap, I would build a dedicated one for smoking.
The PID tune might not be right for a air system vs a liquid system.

  • Like
Reactions: Icefever
I'm not too bad I can follow a wiring dia....or think it through what should it do and what does it do :emoji_laughing:...
Why do you still use a maze, why not feed via the cabinet tube??

I've got my thinking head-on at the moment, I would like to be able to use the pid controller on my beer mash/boiler.
I have a Klarstein boiler that has two elements a 1.5Kw & a 3Kw....I'm now thinking about being able when I want to use it with either the smoker or boiler??

Ice.

Yeah I think you will get the wiring down no problem. After doing 1 and undrestanding it all it's not hard to do additional PIDs.

I use the AMNPS tray because it produces up to 12 hours of perfect Thin Blue Smoke (TBS) with no fooling with it. I do lots of briskets and a good amount of pork butts. That means lots of overnight smokes so I just set the AMNPS up in my mailbox mod and have the electric going on the PID and I go to bed. I have remote thermometers to wake me up if a pellet flame up happens, if the power dies and smoker cools, or when the meat is at a temp for me to check tenderness.

AMNPS tray is awesome!!! No needing to babysit anything when using it and again perfect smoke!

Here is the thread with the PID I built a couple of months ago for my brother:

I think you can easily build your PID to work with your smoker or with your beer brewing setup. You may need to write down both PID settings since heating and response times may be very different. If you build yours somewhat like the one I did below then you can just get a 2nd beer brewing friendly probe and use it for your beer setup and the other you leave at your smoker for the smoker setup. I have a k-type socket (yellow rectangle) I put into the back of this one the PID could be disconnected and brought inside at any point.

I also highly suggest cannibalizing a good, inexpensive, outdoor extension cord (6ft, reuse the wiring for inside the PID) so that you have male and female outlets that don't melt down on you like the cheap crappy Chinese plastic components do. Also it's easier to drill holes into the project box/enclosure than to cut accurate rectangles, so drilling holes and using cord relief grommets and such makes life MUCH easier. Also get a good switch that wont melt down on you. An automotive one or marine breaker switches 40amp rated+ should hold up.



This kind of design should do the trick OR as suggested Lonzinomaker Lonzinomaker you can make a 2nd one for your brew setup.
If you have extra parts and supplies then it is cheap if not then you can simply have 2 different temp probes to use (one for smoker, one for brewing) and then write down your different PID settings.

  • Like
Reactions: Icefever
They are so cheap, I would build a dedicated one for smoking.
The PID tune might not be right for a air system vs a liquid system.
Good point :emoji_thumbsup:... will have to think about this.

I just set the AMNPS up in my mailbox mod and have the electric going on the PID and I go to bed. I have remote thermometers to wake me up if a pellet flame up happens, if the power dies and smoker cools, or when the meat is at a temp for me to check tenderness.

Wow...I've never done an all-night smoke, too many things to go wrong :emoji_wink:.
Now I know it can be done I shall be after any info on how to set the PID, I've started the build got the PID in the box, not sure which to use the SSR ( I have a couple of them,) or the PWM that I have???

I remember reading about using a PWM instead of an SSR is better/safer??? not sure why??

If you have extra parts and supplies then it is cheap if not then you can simply have 2 different temp probes to use (one for smoker, one for brewing) and then write down your different PID settings.

I did think about using a k-type socket, but then as you say I'll be changing the settings every couple of days and that could be a PITA...:emoji_laughing:

Ice.

Good point :emoji_thumbsup:... will have to think about this.



Wow...I've never done an all-night smoke, too many things to go wrong :emoji_wink:.
Now I know it can be done I shall be after any info on how to set the PID, I've started the build got the PID in the box, not sure which to use the SSR ( I have a couple of them,) or the PWM that I have???

I remember reading about using a PWM instead of an SSR is better/safer??? not sure why??



I did think about using a k-type socket, but then as you say I'll be changing the settings every couple of days and that could be a PITA...:emoji_laughing:

Ice.
I don't know much about PWM but my understanding is they are primarily used to convert control signals into switch signals.
The PID's you are using should have no issue sending signals to an SSR for on/off so the PWM may be overkill for these simple applications. If you had a more complex PID and scenario messing with motors of some type then maybe the PWM would be more useful?

You may still want to use some kind of K-type socket or female connector with your box so that you can disconnect your entire PID unit from the smoker and bring it inside.
It can be handy for people to remove the PID. I know a number of guys way up north or in Canada basically put away all their smoking and grilling equipment when winter arrives so I bet they would love to bring the electronics inside to preserve them.

I just bought an Auber Plug-n play PID for my MES 30 and plan on installing it this weekend. Does anyone know if I need to or should keep the original MB controller on the smoker, or can I remove it? Thanks!

I just bought an Auber Plug-n play PID for my MES 30 and plan on installing it this weekend. Does anyone know if I need to or should keep the original MB controller on the smoker, or can I remove it? Thanks!
I bypassed my mes because it was toast anyway. The auber is way better at controlling temps.

Last edited:
  • Like
Reactions: Smokin' Em
I just bought an Auber Plug-n play PID for my MES 30 and plan on installing it this weekend. Does anyone know if I need to or should keep the original MB controller on the smoker, or can I remove it? Thanks!

You can keep it but not really needed. I've never heard of anyone going to a PID and then having to switch back to the original controller. It does keep holes covered if you leave it on?

Just be sure to do the rewire so the PID will work :)

  • Like
Reactions: Smokin' Em
I'm going to experiment with a hotplate controlled by an inkbird temperature control in mine. if the inkbird keeps a stable temperature with the hotplate, then i will rewire the MES, bypassing the time and temperature controls and use the inkbird in place of the nature controls.
