Chef's Choice meat slicer modification....

daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
Well, I got tired of not being able to slice meat thin, like deli thin....
I just made some Pastrami and decided to make my slicer work, "close" to what a deli can do....


..... 2019-3-26 pastrami 001.JPG 2019-3-26 pastrami 002.JPG

I cut a piece of ~0.084 aluminum I bought from Amazon... oversized to the platen on the slicer....
It hangs over the leading edge and the free side of the slicer...
Cleaned the platen and the aluminum sheet.. scuffed the aluminum sheet so the Marine Caulk, polyurethane, would stick... The caulk was put on thick so I could run hot water and sanitation stuff between the plate and the platen to clean any stuff from between... and also sanitize the area...
The plate edges were smoothed with fine sanding paper... The leading corner that is closest to the blade, had a tapered edge so it would not hang up on the housing when it slid by....
The tapered leading edge is just to the right of the blade...
I set the platen just outside the blade to make a very small gap so I could slice meat thin and glued the plate down... There's about a 0.040 gap between the plate and the cutting edge of the blade....
2019-3-26 pastrami 004.JPG .. 2019-3-26 pastrami 003.JPG

The white is the sealer, and showing the gap... Looking at the bottom or the plate....
2019-3-26 pastrami 006.JPG .. 2019-3-26 pastrami 005.JPG

The results are better than I thought.... Perfect very thin sliced meat...
Aluminum Plate
Marine Sealant
I'm a happy camper.... It's beer thirty now....

Last edited:

old sarge

Master of the Pit
OTBS Member
★ Lifetime Premier ★
2,643
502
Joined Nov 26, 2012
Excellent Dave. Did it also eliminate the dreaded tail or did you flip the meat as needed?


indaswamp

Smoking Guru
OTBS Member
6,708
3,323
Joined Apr 27, 2017
This will REALLY come in handy for the guys making dry cured stuff!!!! How thin can you slice now Dave?


daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
Excellent Dave. Did it also eliminate the dreaded tail or did you flip the meat as needed?
Yep.... The tail is GONE... on strami any way... I'll test it on bacon in a month or three.....

This will REALLY come in handy for the guys making dry cured stuff!!!! How thin can you slice now Dave?
I sliced the strami about 1/16".... near as I can tell.... Click on the pics so they will enlarge...


indaswamp

Smoking Guru
OTBS Member
6,708
3,323
Joined Apr 27, 2017
Good deal Dave.....I have a lot of aluminum plate laying around and have access to more...I'll see how the BBB slices but I was wanting thinner slices when I cut up the eye of round I smoked 2 months ago...


SmokinAl

SMF Hall of Fame Pitmaster
Staff member
Moderator
OTBS Member
★ Lifetime Premier ★
46,854
7,702
Joined Jun 22, 2009
Great idea Dave!
I like my meat shaved for roast beef sandwiches.
And I usually have to get out the big slicer to do that.
Would rather use my Chef's choice!
Al


daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
I'm the same on slice thickness.... I've had this idea for some time, and the parts for about 6 months... All it took was 1 sammie made from thick slices to get me in gear... Damn, I'm slow sometimes.... But when I get going..... look out !!!!


SWFLsmkr1

Epic Pitmaster
Staff member
Moderator
OTBS Member
★ Lifetime Premier ★
Group Lead
10,470
3,958
Joined Dec 25, 2010
Great job Dave.


gmc2003

Epic Pitmaster
OTBS Member
10,769
5,355
Joined Sep 15, 2012
Impressive Dave, there's no better feeling then coming up with a solution to a problem.

Point for sure
Chris


daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
Thanks all for your support for an idea I think works well.... Hope you all can get some great results....


old sarge

Master of the Pit
OTBS Member
★ Lifetime Premier ★
2,643
502
Joined Nov 26, 2012
You know Dave, I believe your idea would work well for extending the length of the carriage/tray for things like bacon. Well done!


daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
I extended the length of the tray 5" longer than the platen.... It's now 12" long....
And it's about 1" wider... I did the extra width so it would be easier to run hot tap water between the plate and the platen for cleaning....
As far a being permanent, I can see no reason to want to remove it... There shouldn't be much, if any, crap gets between the plate and the platen...
I do sharpen both blades regularly.... I don't have a regular sharpener... I use a cratex stone in dark brown... Cratex Stones

Last edited:

daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
Thanks coach... Maybe you can use the idea to improve your slicer...


old sarge

Master of the Pit
OTBS Member
★ Lifetime Premier ★
2,643
502
Joined Nov 26, 2012
I extended the length of the tray 5".... It's now 12" long....
And it's about 1" wider... I did the extra width so it would be easier to run hot tap water between the plate and the platen for cleaning....
As far a being permanent, I can see no reason to want to remove it... There shouldn't be much, if any, crap gets between the plate and the platen...
I do sharpen both blades regularly.... I don't have a regular sharpener... I use a cratex stone in dark brown... Cratex Stones
I hadn't noticed from the photos that you extended the be. Great! I have a piece of scrap SS just begging to be trimmed down and put to sensible use. Thanks for planting the seed! Now I have to get off my backside see about it germinating!


tropics

Epic Pitmaster
OTBS Member
★ Lifetime Premier ★
14,149
5,822
Joined Jun 25, 2014
Dave I will be doing this tomorrow need to slice some Roast Beef for sandwich, the Aluminum Sheet is no longer available going to use Plexi glass for now
Richie


daveomak

SMF Hall of Fame Pitmaster
OTBS Member
SMF Premier Member
26,387
3,779
Joined Nov 12, 2010
When I glued the plate to the meat platen, I was sure to leave a fairly large gap between the sheet of aluminum and the platen...
Immediately when finished slicing, I run hot tap water and soap through the gap to rinse out any contaminates that may grow and cause food contaminate problems in the future... A little spray liquid, used to sanitize counter tops , wouldn't hurt either... Make sure it's the food safe stuff.....
The marine sealant works very well.... I suggest using it... It sticks to EVERYTHING, unlike silicone... And put on thick globs, so you can get the space adequate to rinse stuff out of the gap...
